Contact lenses with circuits

Discussion in 'Science, Technology & Car Chat' started by shadowchi, Feb 19, 2008.

  1. shadowchi

    shadowchi ~~♫ ♫ ♪ Himitsu ♪ ♫ ♫ ~~

    609
    68
    1
    [SHOWTOGROUPS]Bionic eyes: Contact lenses with circuits, lights a possible platform for superhuman vision

    Movie characters from the Terminator to the Bionic Woman use bionic eyes to zoom in on far-off scenes, have useful facts pop into their field of view, or create virtual crosshairs. Off the screen, virtual displays have been proposed for more practical purposes -- visual aids to help vision-impaired people, holographic driving control panels and even as a way to surf the Web on the go.
    The device to make this happen may be familiar. Engineers at the UW have for the first time used manufacturing techniques at microscopic scales to combine a flexible, biologically safe contact lens with an imprinted electronic circuit and lights.

    "Looking through a completed lens, you would see what the display is generating superimposed on the world outside," said Babak Parviz, a UW assistant professor of electrical engineering. "This is a very small step toward that goal, but I think it's extremely promising." The results were presented today at the Institute of Electrical and Electronics Engineers' international conference on Micro Electro Mechanical Systems by Harvey Ho, a former graduate student of Parviz's now working at Sandia National Laboratories in Livermore, Calif. Other co-authors are Ehsan Saeedi and Samuel Kim in the UW's electrical engineering department and Tueng Shen in the UW Medical Center's ophthalmology department.

    There are many possible uses for virtual displays. Drivers or pilots could see a vehicle's speed projected onto the windshield. Video game companies could use the contact lenses to completely immerse players in a virtual world without restricting their range of motion. And for communications, people on the go could surf the Internet on a midair virtual display screen that only they would be able to see.

    "People may find all sorts of applications for it that we have not thought about. Our goal is to demonstrate the basic technology and make sure it works and that it's safe," said Parviz, who heads a multi-disciplinary UW group that is developing electronics for contact lenses.

    The prototype device contains an electric circuit as well as red light-emitting diodes for a display, though it does not yet light up. The lenses were tested on rabbits for up to 20 minutes and the animals showed no adverse effects.

    Ideally, installing or removing the bionic eye would be as easy as popping a contact lens in or out, and once installed the wearer would barely know the gadget was there, Parviz said.

    Building the lenses was a challenge because materials that are safe for use in the body, such as the flexible organic materials used in contact lenses, are delicate. Manufacturing electrical circuits, however, involves inorganic materials, scorching temperatures and toxic chemicals. Researchers built the circuits from layers of metal only a few nanometers thick, about one thousandth the width of a human hair, and constructed light-emitting diodes one third of a millimeter across. They then sprinkled the grayish powder of electrical components onto a sheet of flexible plastic. The shape of each tiny component dictates which piece it can attach to, a microfabrication technique known as self-assembly. Capillary forces -- the same type of forces that make water move up a plant's roots, and that cause the edge of a glass of water to curve upward -- pull the pieces into position.

    The prototype contact lens does not correct the wearer's vision, but the technique could be used on a corrective lens, Parviz said. And all the gadgetry won't obstruct a person's view.

    "There is a large area outside of the transparent part of the eye that we can use for placing instrumentation," Parviz said. Future improvements will add wireless communication to and from the lens. The researchers hope to power the whole system using a combination of radio-frequency power and solar cells placed on the lens, Parviz said.

    A full-fledged display won't be available for a while, but a version that has a basic display with just a few pixels could be operational "fairly quickly," according to Parviz.

    [​IMG] [​IMG]

    source:By Hannah Hickey
    News and Information
    uweek.org[/SHOWTOGROUPS]


    CRazy....0.o, we are becoming terminators

  2. BigC

    BigC Well-Known Member

    702
    68
    0
    W/ nanotechnology anything is possible. btw is that a bunny eye???

  3. shadowchi

    shadowchi ~~♫ ♫ ♪ Himitsu ♪ ♫ ♫ ~~

    609
    68
    1
    Yeah i know, but to actually watch tv with your contacts in the future.
    uuuuuh it's a bunny :jump:

    () ()
    (-.-)
    (())(()),

  4. geordi ftw!

    [​IMG]

  5. mr_evolution

    mr_evolution ( • )( •ԅ(ˆ⌣ˆԅ)

    9,967
    590
    57
    I don't think I want that in my eye LoL!

  6. lawltank

    lawltank Well-Known Member

    172
    41
    0
    I have trouble putting the normal ones in my eyes. >.<"

  7. shw

    shw Well-Known Member

    1,295
    86
    0
    very nice
    wonder if he had a tv in his

  8. Rev

    Rev Well-Known Member

    234
    41
    0
    Ultimate way to cheat at school XD? Program all the books on your eye :p

  9. LOL im sure all the teachers will check eyes now.... and man gambling would be so bad...... XD

    and yes with nanotechnology a lot of doors will be opened and challenged.....

  10. ab289

    ab289 Well-Known Member

    3,436
    414
    271
    hhmm .. with xray vision, does that mean the ladies will need to wear lead undergarments?

  11. grado

    grado Member

    8
    26
    0
    that's cool, but still looks like terrible when seeing the rabbit eyes.

  12. Boss Lady

    Boss Lady Well-Known Member

    104
    41
    0
    I dont think this is affordable... and waste of time...

  13. AC0110

    AC0110 Let the Fun Begin

    3,913
    377
    52
    ^
    With technology... price goes down in time... like 70 yrs from now ^^

  14. Choy1314

    Choy1314 Well-Known Member

    386
    53
    0
    Oh yeah.... Xray contact next.... watch out for that guys wink wink haha
